Industrial Belts

MATSUSAKA Narrow vee belt is highly recommended for long span pulley distance and multi-belts drive applications.

Available Types : 3V, 5V, 8V (RMA), SPZ, SPA, SPB, SPC (DIN).

Recommended Applications :

Type	Top width	Thickness	Angle
SPZ	10	8	40°
SPA	13	10	40°
SPB	17	14	40°
SPC	22	18	40°

MATSUSAKA wrapped V-belts are designed to perform high power transmission with reverse bend applications under extreme working conditions.

Special formulated rubber compound
Superior resistant to reverse bending stress
Designed with Polyester cords enabling excellent tensile strength and minimum elongation
Low maintenance costs
High transmission capabilities and horsepower ratings
Superior resistant to shock and pulsating loads
Excellent anti-static, oil, heat and water resistant properties

Recommended Applications : Deployed mainly in Industrial machinery in;

Available Types : A, B, C, D , E, M/Z, FM/9.5

Type	Top width (mm)	Thickness (mm)	Thickness
9.5/FM	9.5	6	40
Z/M	10	6	40
A	13	8	40
B	17	11	40
C	22	14	40
D	32	19	40
E	38	23	40

MATSUSAKA developed the raw-edge cogged series for extreme industrial applications.

Special formulated rubber compound
Excellent side-wall wear resistant
Extra-layered fabric for heavy-duty applications
Good bending stress
Superior resistant to shock and pulsating loads
Designed with Kelvar cords enabling excellent tensile strength and minimum elongation
Superior belt stability eliminating lateral whip, spin or jump off
Good heat dissipating, oil, water resistant and anti-static properties

Recommended Applications : Deployed in;

Industrial machinery and recommended for automotive such as trucks/buses and also it is also suitable for saloon cars.

Available Types: REC-9.5, AX, BX & CX

Type	Top width (mm)	Thickness (mm)	Angle
REC-9.5	9.5	6	40
AX	13	8	40
BX	17	11	40
CX	22	14	40
